Application
Description
A UV printer is a type of digital printer that uses ultraviolet (UV) light to cure or dry the ink as it is printed. Unlike traditional printing methods, UV printers can print directly on a wide range of materials, including plastic, glass, metal, wood, and acrylic. The UV-curable inks are exposed to UV light, which instantly hardens the ink, producing vivid, durable, and scratch-resistant prints. UV printers are commonly used for signage, promotional items, packaging, and custom products.
Specifications
| Model | LC-UV6090 | ||
| Nozzle type | F1080/XP600/i3200/i1600 | ||
| Number of nozzles | 2-4 pcs | ||
| Print mode | Sketch mode 11㎡/h | Production mode 5.5㎡/h | Quality mode 3㎡/h |
| UV lamp configuration | Water-cooled | ||
| Ink type | UV ink | ||
| Ink color | CMYK/CMYK/Lc/Lm+W(white)+V(Varnish)+V(Gold Varnish) | ||
| Cartridge capacity | 1500ml per color | ||
| Ink supply method | Positive pressure continuous ink supply | ||
| Ink curing method | LED Curing | ||
| Print size | 600*900 mm | ||
| Print height | 0-150 mm (Electromagnet automatic height measurement device) | ||
| Fixture configuration | Cylinder/pen fixture (optional) | ||
| Rip software | 6.1UV Maintop/PhotoPrint | ||
| Printing platform | Vacuum Adsorption platform | ||
| Print interface | Network port | ||
| Operation system | Win10 | ||
| Image file format | TIFF/PDF/PNG/JPG | ||
| Machine power | 1200W | ||
| Environmental requirements | Operating temperature:20-35℃;Working humidity: 35-70%Rh | ||
| Power Specifications | AC 220V±10%,50/60 ±1HZ | ||
| Machine size | 1700mm*1650mm*1278mm(L*W*H) | ||
| Machine N.W | 253 kg | ||
| Package size | Vacuum Adsorption Platform | ||
Optional Items
Get a Quote Now
Related Video
Factory Strength
A Powerful Printer Manufacturer From China Since 2003
20+ Years Printer Factory
Technical support
Support methods usually include telephone support, online customer service, remote support, etc.
Printing supplies
Locor manufacturers or authorized dealers usually provide corresponding inks, powder films and other consumables.
Spare parts
We usually provide customers with original accessories (such as boards, ink sacs, motors, etc.).
